1 - 4 Core Metal Non-Metal Ftth Fiber Optic Drop Cable With 2 Strength Member

    Buy cheap 1 - 4 Core Metal Non-Metal Ftth Fiber Optic Drop Cable With 2 Strength Member from wholesalers

    Buy cheap 1 - 4 Core Metal Non-Metal Ftth Fiber Optic Drop Cable With 2 Strength Member from wholesalers
    • Buy cheap 1 - 4 Core Metal Non-Metal Ftth Fiber Optic Drop Cable With 2 Strength Member from wholesalers
    • Buy cheap 1 - 4 Core Metal Non-Metal Ftth Fiber Optic Drop Cable With 2 Strength Member from wholesalers

    1 - 4 Core Metal Non-Metal Ftth Fiber Optic Drop Cable With 2 Strength Member

    Ask Lasest Price
    Brand Name : FURONG
    Model Number : FTTH Self Support Bow-type 2 core
    Certification : ROHS
    Price : negotiation
    Payment Terms : T/T or western Union, D/P
    Supply Ability : 10,000km per month
    Delivery Time : 7 working days after received your payment
    • Product Details
    • Company Profile

    1 - 4 Core Metal Non-Metal Ftth Fiber Optic Drop Cable With 2 Strength Member

    1 - 4 Core Metal Non-Metal Ftth Fiber Optic Drop Cable With 2 Strength Member


    FTTH & FTTX cables include indoor and outdoor applications. Fiber count from 1fiber to 8fibers as per requested, G652D and G657A fibers available, with LSZH jacket, FRP strength member & Steel strength member. part number: GJXH, GJXFH, GJYXCH, GJYXFCH, GYPHA, GYPFHA...


    Cable Parameters

    Fiber core

    Cable

    type

    Size

    mm

    Weight

    kg/km

    Tensile force

    long/short term

    (N)

    Crush force

    long/short term

    (N/100mm)

    Applicable temperature range

    1-4

    GJXFH

    3.0x2.0

    9.0

    40

    80

    500

    1000

    -20°C~+60°C

    1-4

    GJXH

    3.0x2.0

    9.5

    100

    200

    1000

    2200

    Features

    1, Good mechanical and environmental performance;

    2, Flame-retardant properties to meet the requirements of the relevant standards;

    3, The mechanical characteristics meet the requirements of the relevant standards;

    4, Soft,flexible,easy to splice,and with big capacity date transmission;

    5, Meet various requirements of market and clients.


    Options


    1, Fiber Type:G.652A/BCD,G6.57 or G655A/B/C single-mode fiber,A1a or A1b multimode fiber,or other types of fiber;

    2, Jacket Material: Environmental flame-retardant polyvinyl chloride(PVC),environmental low smoke zero halogen flame-retardant polyolefin (LSZH),environmental thermoplastic polyurethane(TPU),or other contracted material;

    3, Jacket Color:(including color of fiber )meets the requirements of relevant standards,or other contracted dimension;

    4, Delivery Length:1KM or 2km ,or other contracted length

    5, Other Requirements:other contracted special requests.


    Application

    1. Adopted to FTTH indoor distribution
    2. As pigtail of communication equipment
    3. Suitable for communication equipment
    4. Can be installed conveniently

    Our advantage

    1. Professional cable manufacturer.
    2. We provide good quality FTTH cable with manufacture competitive price
    3. Best delivery time
    4. OEM service provide,Your own logo and own design are welcomed.
    5. Long distance factory review by video talk
    6. Can be customized production of fiber optic cable
    7. 30 years cable service life , even 60 years cable service life.
