    Fixed Fiber Optic Attenuator Single Mode SC LC FC ST MU Connector ,1db - 30db Fiber

    Ask Lasest Price
    Brand Name : FURONG
    Model Number : Fiber Optic Attenuator
    Certification : ROHS SGS
    Price : Neogotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30000 PCS per day
    Delivery Time : 3-10 days
    • Product Details
    • Company Profile

    Fixed Fiber Optic Attenuator Single Mode SC LC FC ST MU Connector ,1db - 30db Fiber

    Fixed Fiber Optic Attenuator Single Mode SC LC FC ST MU Connector ,1db - 30db Fiber


    Quick Detail:

    1. Name: Fixed Fiber optic attenuator
    2. Mode: Singlemode, Multimode
    3. Operating Wavelength: 1310nm, 1550nm, 850nm, 1300nm
    4. PC, UPC, and APC polish types optional
    5. attenuation fiber inside
    6. SC,LC,FC,ST,MU Optional


    Description:


    Attenuators are also used to balance out transmission lines that otherwise would have unequal signal levels.


    Features:

    1. Precision control of attenuation range
    2. Wide attenuation range
    3. Environmentally Stable and Reliable
    4. High Directivity, Accurate Size
    5. Precision ceramic ferrule


    Application:

    1. Low back reflection and Low PDL
    2. High precision attenuation value
    3. Precision control of attenuation range
    4. Wide attenuation range
    5. Environmentally Stable and Reliable
    6. High Directivity, Accurate Size


    Specification:

    ItemParameter
    ModelFixed, Female&Male, In-line, Variable
    Operating WavelengthSM:1310/1550nm MM: 850/1300nm
    Attenuation Range1~30dB
    Return LossPC:≥50dB UPC: ≥55dB APC: ≥60db
    Attenuation Tolerance≤+/-0.5(1-10dB) or ≤+/-1.0(11-30dB)
    Maximum Optical Input Power1000mW
    Polarization Dependent Loss≤0.1dB
    Working Temperature-40°C~+75°C
    Storage Temperature-40°C~+ 85°C
    Humidity95%RH

    Our advantage


    1. Professional manufacturer.
    2. We provide good quality Fiber Optic solution with manufacture competitive price
    3. Best delivery time
    4. OEM service provide,Your own logo and own design are welcomed.
    5. Long distance factory review by video talk
    6. Can be customized production of fiber optic solution


    LC attenuator
